Leak Testers
ELT-201WP
Features
- Meets USP specifications and packaging standards
- 5.7 inch graphical touch screen display
- Programmable vacuum level and hold time
- Slow venting for better results
- Validation report printout (Serial / LAN)
- Oil-less vacuum pump
- Weighing scale interface to get results
- Tolerance range setting to give pass / fail results
- Programmable 50 methods and storage of 50 product data
- Embedded printer for printing reports
- Ideal for checking leakage of packed strips, blisters, small sachets and ampoules
Specifications
| Model | ELT-201WP |
|---|---|
| Vacuum level | 2 mmHg to 650 mmHg |
| Timer | Maximum can be set up to 00.01 minutes Minimum can be set up to 99.59 min |
| Vacuum setting level | Vacuum can stabilize to the set value +5 mmHg within 90 secs |
| Power requirement | 230V. 50Hz |
| Power | 300 VA |
| Dimension ( W x L x H) |
396 x 245 x 228 |
ELT-201P
Features
- Meets USP specifications and packaging standards
- 5.7 inch graphical touch screen display
- Programmable vacuum level and hold time
- Slow venting for better results
- Validation report printout (Serial / LAN)
- Oil-less vacuum pump
- Weighing scale interface to get results
- Tolerance range setting to give pass / fail results
- Programmable 50 methods and storage of 50 product data
- Embedded printer for printing reports
- Ideal for checking leakage of packed strips, blisters, small sachets and ampoules
Specifications
| Model | ELT-201WP |
|---|---|
| Vacuum level | 2 mmHg to 650 mmHg |
| Timer | Maximum can be set up to 00.01 minutes Minimum can be set up to 99.59 min |
| Vacuum setting level | Vacuum can stabilize to the set value +5 mmHg within 90 secs |
| Power requirement | 230V. 50Hz |
| Power | 300 VA |
| Dimension ( W x L x H) |
396 x 245 x 228 |
LT-101P
Features
- Meets USP and package specifications
- Ideal for checking leakage of packed strips, blisters, small sachets and ampoules
- Programmable vacuum level and hold time
- Slow venting for better results
- Validation report printout
- Oil-less vacuum pump
- 5.7 inch graphical touch screen display
- Tolerance range setting to give pass / fail results
- Programmable 50 methods and storage of 50 product data
- Ideal for checking leakage of packed strips, blisters, small sachets and ampoules
Specifications
| Model | ELT-201 |
|---|---|
| Vacuum setting level | Vacuum can stabilize to the set value +5 mm of Hg within 30 secs |
| Vacuum level | 2mm Hg 650 of Hg |
| Timer | Maximum can be set up to 99 minutes Minimum can be set up to 1 min |
| Power requirement | 230V. 50 Hz |
| Power | 300 VA |
| Dimension ( W x L x H) |
377 x 248 x 264 |
